CE Double Belts Automatic Continuous Frying Machine

Double Belts PLC Control CE Certified Factory Continuous Frying Machine

Double Belts PLC Control CE Certified Factory Continuous Frying Machine Detailed Description:
1. Double mesh belt: The upper mesh belt is in the shape of a wave and has a baffle plate to drive the transfer of light materials such as potato chips to make it evenly fried to achieve better frying effect.
2. PLC control: To control the whole machine working, adjust temperature and mesh belt speed
3. Automatic lifting device: Lift the mesh belt for easy cleaning inside.
4. Filter screen: Preliminary rough filtration of residue.
5. Oil filter device: Equipped with this device according to customer needs.
6. Oil storage tank: Equipped with this device according to customer needs.

Double Belts PLC Control CE Certified Factory Continuous Frying Machine Relevant Data:

Double Belts PLC Control CE Certified Factory Continuous Frying Machine Introduce:

CONTINUOUS FRYER: Automatic continuously working; Pot body made of 4mm 304 stainless steel,baseboard is 5mm thickness.Pot body shell made of 1mm 304 stainless steel.Water leakage test to make sure the leakproofness after welding.Aluminum silicate insulation materials is flled between pot body and shell.
HOISTING SYSTEM: Can hoist the fume exhaust cover individually.Can hoist the cover, belt holder and heating tubes together Convenient to clean the mesh belt and fume exhaust cover.Use the safety bumper to make sure the belt holder can not fall down when it lifted.Automatically cut off heating tubes' power when hoisting the cover.
AUTOMATIC CONTROL BOX: Oil temperature is tested by sensor and transfer to controller.The oil temperature and frying time can be set by the control system all electrical part is famous brand such as Siemens, Schneider PLC touch screen system which can control the frying time, temperature , speed and so on.
MESH BELT CONVEYING SYSTEM: Belt speed is frequency controlled.Different belt based on request .The exhaust cover and belt holder can be lifted individually, easy cleaning.The bearing and seat is made of stainless steel 304.The gap of double belt is 30 – 80 mm.Transmission use gear reducer with low noise.
LAMPBL ACK EXHAUSTING SYSTEM: Exhaust cover is made of 2 mm stainless steel 304.The cover and exhaust pipes have vapour extraction system.Two fume Exhaust pipes ,each is 6m long,made of 304 stainless steel.Axial flow fan installed on the end of each exhaust.Control valve installed on the bottom of exhaust seat.
OIL TANK: Oil tank is used to store the oil after working for cleaning the frying machine. It can pump oil back to the oil tank from fryer. It also can automatic fill the oil to fryer during frying.Model: YG 2ton.Volume of oil: 2000kg.Material: SUS304 stainless steel with heating system.

Double Belts PLC Control CE Certified Factory Continuous Frying Machine Show:

FAQ:
1. Who are we?
We are based in Shandong, China, start from 2020,sell to Southeast Asia(40.00%),Africa(20.00%),South America(10.00%),North
America(8.00%),Western Europe(8.00%),Eastern Asia(5.00%),Oceania(2.00%),Eastern Europe(2.00%),Domestic Market(1.00%),South
Asia(1.00%),Mid East(1.00%),Northern Europe(1.00%),Central America(1.00%). There are total about 101-200 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3. What can you buy from us?
Food machine,Frying machine,packaging machine,Cleaning and processing production line,Pasteurization production line
4. Why should you buy from us not from other suppliers?
The company has 13000 square meters of factory buildings and 70 employees.With 10 years of export experience, our products are exported to America, Europe, Africa, Southeast Asia and other countries and regions.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow.
