1000L Commercial Steam Jacketed Kettle With High Shear Mixer

1000L Commercial Steam Jacketed Kettle With High Shear Mixer
1000L Commercial Steam Jacketed Kettle With High Shear Mixer 1000L Commercial Steam Jacketed Kettle With High Shear Mixer

Large Image :  1000L Commercial Steam Jacketed Kettle With High Shear Mixer

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD 2300 PER SET
Packaging Details: wood case
Delivery Time: 8-10 working days
Payment Terms: L/C, T/T, Western Union

1000L Commercial Steam Jacketed Kettle With High Shear Mixer

Description
Product Name: Jacket Kettle Material: Stainless Steel 304/316
Application: Food Cooking Industrial Jacketed Kettle Usage: Industrial Food Jacketed Kettle Price
Agitator: Import Material Scraper Blade Machinery Function: Cooking And Mixing, Fruit Jam Cooking Machine, Mix Ketchup Machine
Application Field: Vegetable Processing Plant, Cannery, Meat Processing Plants Type: Cooking Equipment, Steel Tilting Heated Pots
Motor: Taiwan GPG Motor And Reducer Avaible
High Light:

SS304 commercial cooking kettle

,

1000L commercial steam jacketed kettle

,

commercial steam jacketed kettle

stainless steel industry kettle inox Food Processing Application commercial steam jacketed kettle with high shear mixer



stainless steel industry kettle inox Food Processing Application commercial steam jacketed kettle with high shear mixer
Description:
Designed according to GMP standard, widely used for cooking feeding material in the food-processing, cosmetics and pharmaceutical industries
Construction:
Kettle, bracket, worm wheel and worm etc.
Heating method:
By electricity (oils or water), by steam, by gas
Material:
SS304/SS316L
Capacity:
50L-1000L
Agitator Type:
With PTFE scraper(20-25rpm), optional frame mixer(36rpm) and homogenizer(3000rpm)
Speed:
Constant speed in standard, stepless speed control and frequency control of motor speed avaible
Motor:
Standard Taiwan GPG motor, optional horizontal type
Jacket:
Two layers no isolation in standard
Surface treatment:
Inner polished and outside polished
Application scope:
Dairy, food, beverage, pharmacy, cosmetic, etc
Standard configuration:
SUS304 electric controller, Taiwan GPG motor and Schneider component,full stainless steel bracket(standard 202, 304 optional)
Optional configuration:
VFD, wheels, pressure, open cover, homogenizer etc.



1000L Commercial Steam Jacketed Kettle With High Shear Mixer 0

Model
Volume Diameter×Height
Form
Pressure(mpa)
Inlet&Outlet
Motor Power
JCG-50
50
60×45
Tilting
Stirring
0.3
1/2”
0.75kw
JCG-100
100
70×50
Tilting
Stirring
Fixed
0.3
3/4”
0.75kw
JCG-200
200
80×55
Tilting
Stirring
Fixed
0.3
3/4”
1.5kw
JCG-300
300
90×65
Tilting
Stirring
Fixed
0.3
3/4”
1.5kw
JCG-400
400
100×75
Tilting
Stirring
Fixed
0.3
3/4”
1.5kw
JCG-500
500
110×85
Tilting
Stirring
Fixed
0.3
1”
2.2kw
JCG-600
600
120×95
Tilting
Stirring
Fixed
0.3
1”
2.2kw
JCG-1000
1000
1400×115
Tilting
Stirring
Fixed
0.3
1”
3.7kw



1000L Commercial Steam Jacketed Kettle With High Shear Mixer 1

1000L Commercial Steam Jacketed Kettle With High Shear Mixer 2



a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.

We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).

We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.
